With a completely redesigned frame, front triangle tubeset taken from Thunderbird frames, 1.8” tapered head tube, Marzocchi Z1 fork, and powerful 4-piston Magura MT5N brakes this bike claims tracks and even freeride lines like no hardtail before. For more comfortable riding, the Hornet pro is equipped with a dropper post.
With a completely redesigned frame, front triangle tubeset taken from Thunderbird frames, 1.8” tapered head tube, Marzocchi Z1 fork, and powerful 4-piston Magura MT5N brakes this bike claims tracks and even freeride lines like no hardtail before. For more comfortable riding, the Hornet pro is equipped with a dropper post.
MAIN FEATURES
- All new Hornet pro frame, with redesigned shape front triangle tubeset taken from Thunderbird FR frame
- 1.8" tapered head tube with 60mm bottom headset bearing to survive the most hardcore freeride actions
- Legendary Marzocchi Z1 150mm travel fork, with 36mm upper legs and Grip damper
- FSA comet Heavy Duty forged crankset with 24mm chromoly spindle and 32T direct mount narrow-wide chainring
- powerful Magura MT5N 4-piston brakes, with 203/180mm front/rear rotor
- Maxxis Minion DHF 27.5x2.6 tubeless-ready tires with EXO protection
- Oversized 35mm cockpit with all new 810mm wide Viper handlebar and short Viper stem
SPECIFICATION
- WHEEL SIZE: 27.5"
- FRAME: glossy Dark Chrome, AL 6061-T6
- FRAME SIZE: Medium, Large, XLarge
- COLOR: glossy Dark Chrome
- FORK: Marzocchi Z1 27.5" Grip, Boost, travel 150mm, axle 15mm, tapered
- HEADSETS: Dartmoor Storm OEM
- DERAILLEUR: Shimano Deore M5100 1X11
- SHIFTER: Shimano Deore M5100-R, 11–speed
- BRAKES: Magura MT5N, 4-piston brakes, rotors Magura Storm HC front 203mm/rear 180mm
- CRANKSET: FSA Comet Heavy Duty, 175mm (XL, L) / 170mm (M)
- CHAINRING: Direct mount 32T
- CASSETTE: Sunrace CSMS7, 11-51T
- CHAIN: KMC X11
- PEDALS: without
- RIMS: Dartmoor Shield Wide 27.5", 32H, F/V, tubeless ready
- FRONT HUB: Dartmoor Reel Boost 110x15mm, 32H
- REAR HUB: Dartmoor Reel Boost 148x12mm, 32H
- TIRES: Maxxis Minion DHF 27.5x2.6, Foldable, EXO/TR
- HANDLEBAR: Dartmoor Viper 810mm, Ø35mm
- STEM: Dartmoor Viper, Ø35mm
- GRIPS: Dartmoor Roots
- SADDLE: Dartmoor Trail v.2
- SEATPOST: X-Fusion Manic, travel 170mm (XL, L) / 150mm (M), Ø30.9mm
- WEIGHT: 15.50kg (w/o pedals)
